Bronze is an alloy. Characteristics of bronze

Bronze is an alloy based on copper.Auxiliary metals can be nickel, zinc, tin, aluminum and others. In this article we will consider the types, technological features, chemical. composition of bronze, as well as methods of its production.bronze is an alloy

Classification

1.The chemical composition of this metal is divided into two groups. The first is tin bronzes. In them, tin is the main alloying element. The second is tinless. Below, we will discuss this in more detail.

2. According to technological features, bronze is usually divided into deformable and foundry ones. The former are well processed under pressure. The latter are used for shaped castings.

This metal in comparison with brass hasmuch better anti-friction, mechanical properties, as well as corrosion resistance. In fact, bronze is an alloy of copper and tin (as the main auxiliary element). Nickel and zinc here are not the main alloying elements, for this use components such as aluminum, tin, manganese, silicon, lead, iron, beryllium, chromium, phosphorus, magnesium, zirconium and others.bronze application

Tin bronzes: Foundry

Let's see what ismetal. Tin bronze (the photo below shows cast details) is an alloy that has a lower fluid flow than other types. However, it has an unimportant volumetric shrinkage, which makes it possible to obtain shaped bronze castings. These properties cause the active use of bronze when casting antifriction parts. Also, the alloy in question is used in the manufacture of valves intended for use in an aqueous medium (including in seawater) or in steam, in oils and under high pressure. There are also so-called non-standard foundry bronzes of responsible designation. They are used in the production of bearings, gears, bushings, parts of pumps, low-sealing rings. Such parts are designed to work under high pressure conditions, at high speeds and small loads.

Lead bronze

This subspecies of foundry tin alloysIt is used in the manufacture of bearings, seals and shaped castings. Such bronzes are characterized by low mechanical properties, as a result of which, in the process of manufacturing bearings and bushings, they are simply applied to a steel substrate in the form of a very thin layer. Alloys with an increased content of tin have higher mechanical properties. Therefore, they can be used without a steel base.bronze pictures

Tin bronzes: deformable

Alloys, processed by pressure, it is customary to divideon the following groups: tin-phosphorous, tin-zinc and tin-zinc-lead. They have found their application in the pulp and paper industry (from them make grids) and engineering (production of springs, bearings and machine parts). In addition, these materials are used in the manufacture of bimetallic products, bars, belts, bands, gears, gears, bushings and gaskets of high-loaded machines, tubes of instrumentation, pressure gauges. In electrical engineering, the widespread use of bronze (deformable) is explained by excellent mechanical properties (along with high electrical characteristics). It is used in the manufacture of current-carrying springs, plug-in connectors, contacts. In the chemical industry, tin wire is produced from tin bronzes, in precision mechanics - reinforcement, in the paper industry - scrapers, in automotive and automotive - bushings and bearings.

These alloys can be supplied in a particularly hard,solid, semi-solid and soft (annealed) state. Tin bronzes are usually treated cold (rolling or drawing). Hot metal is only pressed. Under pressure, bronze is perfectly processed both in cold and hot form.bronze characteristics

Beryllium bronze

This alloy, belonging to the groupdispersion-hardening metals. It has high mechanical, physical and elastic properties. Beryllium bronze has a high level of heat resistance, corrosion resistance and cyclic strength. It is resistant to low temperatures, it does not magnetize and does not give out sparks when striking. Tempering of beryllium bronzes is carried out at temperatures of 750-790 degrees Celsius. Addition of cobalt, iron and nickel contributes to the thermal processing slowing down the rate of phase transformations, this greatly facilitates the technology of aging and hardening. In addition, the addition of nickel contributes to an increase in the temperature of recrystallization, and manganese can replace, albeit not fully, expensive beryllium. The above bronze characteristics make it possible to use this alloy in the manufacture of springs, springing parts, and membranes in the watch industry.

Copper Alloy with Manganese

Such bronze is distinguished by special highmechanical qualities. It is processed by pressure, both in the cold and in the hot state. This metal is characterized by high heat resistance, as well as corrosion resistance. A copper alloy with the addition of manganese has found wide application in furnace fittings.chemical composition of bronze

Silicon Bronze

This alloy, which includes nickel, is less common- manganese. Such a metal is characterized by ultra-high mechanical, antifriction and elastic properties. At the same time, silicon bronze does not lose its plasticity in conditions of low temperature. The alloy is well soldered, processed by pressure at both high and low temperatures. The metal in question is not magnetized, it does not spark at impacts. This explains the widespread use of bronze (silicon) in marine shipbuilding in the manufacture of antifriction parts, bearings, springs, grids, evaporators, nets and guide bushings.

Foundry all-tin alloys

This type of bronze is characterized by goodcorrosion, antifriction properties, as well as high strength. They are used for the manufacture of parts that are used in particularly difficult conditions. These are, for example, gears, valves, bushings, gears for powerful turbines and cranes, worms that work in the paddle with reinforced steel parts, bearings operating under high pressure and shock loads.how to make bronze

How to make bronze?

The manufacture of this metal must be carried out inSpecial furnaces used for smelting copper alloys. Charge for bronze can be made of fresh metals or with the addition of secondary waste. The melting process is usually carried out under a layer of flux or charcoal.

Process with use of charge from fresh metalsoccurs in a certain sequence. First, the required amount of flux or charcoal is loaded into a heavily heated furnace. Then put copper there. After waiting for its melting, raise the heating temperature to 1170 degrees. After this, the melt must be deoxidized, for which phosphorous copper is added. This process can be carried out in two steps: directly in the oven, and then in the ladle. In this case, the additive is introduced in equal proportions. Further, the necessary alloying elements heated up to 120 degrees are added to the melt. Refractory components should be introduced in the form of ligatures. Further, the molten bronze (the photo below shows the smelting process) is mixed until all the added substances are completely dissolved and heated to the prescribed temperature. When issuing the resulting alloy from the furnace, before casting, it must be finally deoxidized by a residue (50%) of copper phosphorous. This is done to release bronze from oxides and increase the fluidity of the melt.

Smelting on the basis of negotiable materials

In order to make bronze usingsecondary metals and waste, the smelting should be carried out in the following order. First, melted copper and deoxidize it with phosphorous additives. Then they add circulating materials to the melt. After this, complete melting of the metals is awaited and the alloying elements are introduced in the appropriate sequence. In the event that the burden consists of a small amount of pure copper, you must first melt the recycled metals, and then add copper and alloying elements. Melting is carried out under a layer of flux or charcoal.

After melting the charge and heating it tothe required temperature is the final deoxidation of the mixture with phosphorous copper. The melt is then covered with calcined carbon or dried flux from above. The consumption of the latter is 2-3 percent of the mass of the metal. The heated melt is aged for 20-30 minutes, periodically mixed, and then the separated slag is removed from its surface. All bronze is ready for casting. For better removal of slag in the ladle, you can add quartz sand, which thickens it. To determine whether bronze is ready for casting into molds, a special technological test is carried out. The fracture of such a sample must be uniform and clean.

to make bronze

Aluminum bronze

It is an alloy of copper and aluminum as an alloyingelement. The process of melting this metal differs significantly from the above, which is explained by the chemical characteristics of the auxiliary component. Consider how to make bronze using aluminum alloying components. In the manufacture of this type of alloy using recycled materials in the charge, the deoxidation operation with phosphorous components is not used. This is because the phosphorus is characterized by a lower affinity for oxygen molecules than aluminum. You should also know that this type of bronze is very sensitive to overheating, so the temperature should not exceed 1200 degrees. In an overheated state, aluminum is oxidized, and the bronze alloy is saturated with gases. In addition, the oxide formed during the smelting of this type of bronze is not restored by the addition of deoxidizers, and it is very difficult to remove it from the melt. The oxide film has a very high melting point, which significantly reduces the fluidity of bronze and causes a marring. Melting is carried out very intensively, on the upper limits of the heating temperatures. In addition, do not delay the ready melt in the oven. When melting aluminum bronze as a covering layer, it is recommended to use flux, which consists of 50% of soda ash and 50% of cryolite.

Ready melt before casting by moldsRefine by introducing into it manganese chloride or zinc chloride (0.2-0.4% of the total mass of the charge). After this procedure, the alloy should be allowed to stand for five minutes until the gas evolution ceases completely. After that, the mixture is brought to the required temperature and poured into molds.

In order to prevent segregation into a melt of bronzewith a high content of lead impurities (50-60%) it is recommended to add 2-2.3% nickel in the form of copper-nickel ligatures. Or as a flux, it is necessary to use the alkali metal sulphate salt. Nickel, silver, manganese, if they are part of the bronze, should be introduced into the melt before the tin additive procedure. In addition, to improve the quality of the resulting alloy, it is sometimes modified with minor additives based on refractory metals.
