How to make an aerosleigh with your own hands
Can I make an aerosleigh with my own hands? Let's look for an answer to this question. Are there any reliable aerosleighs built with their own hands at home? Not every person is willing to trust his hands and what he can do himself.
Homemade aerosleighs are a rather interesting form of transport. The fact is that they are moving at the expense of the propeller, in the people it is also called a propeller.
Most often the construction of the aerosleigh is three-ski. Sometimes there is a four-legged, then they can be moved not only through the snow, but also on the water surface.
Imagine how you rush through the snowthe plain is faster than the wind, the whirlwind of snow rises behind you - all this is possible and realistic, if you have an aerosleigh. It is very convenient, fast, and most importantly, a simple mode of transport. Anyone who is equipped with the technique "on you" will be able to build an aerosleigh with his own hands.
Consider how to make them yourself. The material is a tree. The construction will be three-track. The longitudinal beam of the body and the transverse one, on which we will attach the rear skis, will be made of pine bars. Take bars measuring 35 to 40 mm, they will be fastened with bolts. Pay attention to the docking nodes, there you need to install metal angles, as well as washers, necessarily large diameter, as they will prevent the crumpling of the tree.
Where there will be a turntable forfront skiing, as well as where the engine and rear skis are fastened (ski suspension), braces, metal plates and squares should be provided. The ski is again wooden. The hull, or rather its front part, should be studded. On the hood you can install a bicycle headlight, and on the sides - metal footboard. Seat for the driver can be made from a piece of plywood about a millimeter thick 8. The seat must rest against two springs, which we borrow from the saddle for a bicycle. It is important to pay attention to the fact that the bars securing the engine must be of different lengths. The rear bar is longer, it will serve as a fence against the propeller.
On the back skiing you need to make the so-calledstaples, pigs, you can make them from strips of steel size 30 to 5 mm. Skiing should be collected with the help of three plates of plywood, which should be approximately 4 mm thick, they will be fastened with casein glue. Plywood at the edges should be reinforced with bars, preferably oak. The soles of skis should have longitudinal cuts, and they must be fenced with sheet iron. This is to ensure that when you stop the aerosleigh not buried in the snow. The front ski (its turn) will control the aerosleighs.
We will have a cable transmission from the steering column. To control the engine, it is necessary to build levers: the gas lever and the ignition timing lever. Wiring is borrowed from a motorcycle, it will be either a cable or wire, but necessarily in a flexible shell. The engine will be a launcher PD-10 from the tractor, on it we will install a cylinder for air cooling, also from a motorcycle, for example from IZh-56. Above the engine, install the fuel tank. Fuel will be supplied by gravity. That's all - before you aerosleigh self-made. They can be cut through snow-covered fields or simply over snow-covered terrain. The main thing is to do everything on conscience, firmly and accurately, in no case your vehicle collapsed during the movement. As you can see, you can make an aerosleigh with your own hands, you just need to make efforts.
