Phyto LED lamp



Production of the LED lamp for plants


To begin, mark the profile for drilling holes for mounting LEDs. We drill 2 mm with a drill, first 2 holes for one LED, try to fasten it in place and, if everything fits well, we drill the others. Next, we smear the substrate of the LED with a heat-conducting paste with a thin layer, with the expectation that when attaching the LED with bolts, not a lot of paste would come out under the substrate of the LED. It is necessary that there is no air under the LED, and there is good heat transfer. The better the cooling of the LED, the longer it will work.
Phyto lamp assembly.
Phyto LED lamp

The second LED is fixed so that its minus is opposite the plus of the first. And so all the rest.
Solder driver.
When all the LEDs are fixed, you need to solder them in series, minus one to the plus of the other and so on. The soldered chain is soldered to the driver placed in the box and attached to the profile on the reverse side of the LEDs.
On the driver there is a designation + and - plus usually a wire of red or pink color. Plus chains of LEDs to the driver plus and minus, respectively, to the minus. On the other hand, the power is connected to the driver. It is better to buy a driver with 220 volt power. If you have one, then we solder the wire with the plug and everything is ready.
